    Factory Price Inducrtion Soldering Machine of Optimize Coaxial Cable

    Ask Lasest Price
    Brand Name : OURUIDA
    Model Number : UHF-5KW
    Certification : CE ,ISO, ROHS,GSG
    Price : Negotiation
    Payment Terms : Western Union, T/T, L/C, D/A, MoneyGram
    Supply Ability : 1000SETS /Month
    Delivery Time : 1-5days
    • Product Details
    • Company Profile

    Factory Price Inducrtion Soldering Machine of Optimize Coaxial Cable

    Factory Price Inducrtion Soldering Machine of Optimize Coaxial Cable


    Induction Soldering machine :

    Induction soldering is a process in which two or more metal items are joined together by melting and flowing a filler metal (solder) into the joint interface.

    The filler metal (solder) has a lower melting point than the workpieces being assembled. Induction soldering heats the workpieces in an RF (Radio Frequency) filed without making any physical contact with the parts.

    Unlike welding, induction soldering does not involve melting of the joints. Induction Brazing, on the other hand, significantly differs from soldering because it is performed at higher temperatures.

    Induction Soldering often results in a bit weaker joint compared to a brazed one but this is a desirable result for many applications in various industries, especially when you work with sensitive electronics or small components. Induction heating is a perfect solution as it allows you to control the process of soldering and avoid thermal stress.

    Factory Price Inducrtion Soldering Machine of Optimize Coaxial CableFactory Price Inducrtion Soldering Machine of Optimize Coaxial CableFactory Price Inducrtion Soldering Machine of Optimize Coaxial Cable

    The Advantages of induction soldering machine :

    1• Voltage, Power, Current
    2. Limit Settings
    • Current, DC Volts, Output Volts, Power, Frequency
    3. Cooling System
    • Compact air-cooled power supply design with automatic fan control
    4. Control Modes
    • Operator controls: between Automatic, Remote, or Local
    5.
    • Multiple user programs and programmable parameters
    6. Frequency Response
    • Full power delivery within specified frequency range (see Specifications tables)
    7. Load Adaptation
    • Variable ratio output isolation transformer for load matching across wide-range loads and coils
    8. Precision Power Control
    • Power adjustment: 1% to 100% in 1% increments
    9. Digital Interface
    • Digital I/O Interface board: Remote Start/Stop function
    10. External Control
    • External power control input: 0-10V or 4-20mA analog signals
    11. Thermal Management
    • Temperature monitoring & control
    • Temperature regulator (supports standard IR sensor input)
    12. Communication
    • Serial Interface: RS-485
    13. Diagnostics
    • Data logging and remote diagnostics capability
    14. Automation Integration
    • Automation Upgrade Kit: Enables remote power-up when integrated into automated systems

    The technical Parameters of UHF-5KW

    NameInduction Soldering machine
    Rated Input VoltageSingle 220V-230V
    Rated Input Current22A
    Max Input power5KW
    Frequency500khz-1MHZ
    Work Power"Continuously Adjustable Output Power 0% - 100%"
    Cooling systemWater Cooling system
    Contorl modelfoot switch/ temperature control device/ start-stop
    ApplicationsSoldering, Brazing, Welding, Forging. Annealing, Hardening, Heat treatment ....
    Machine size405mm*315mm*155mm
    Factory Price Inducrtion Soldering Machine of Optimize Coaxial CableFactory Price Inducrtion Soldering Machine of Optimize Coaxial CableFactory Price Inducrtion Soldering Machine of Optimize Coaxial CableFactory Price Inducrtion Soldering Machine of Optimize Coaxial Cable

    ​APPLICATIONS:
